STATIONARY CONCRETE PUMPS

BSA 1005 D ‒ BSA 1400 HP-E

Putzmeister develops, produces, sells and serves its customers worldwide with technically high-quality and service-oriented machines in the following areas: Placing of concrete, Truck-mounted concrete pumps, Stationary concrete pumps, Stationary placing booms and accessories, industrial technology, pipe delivery of industrial solids, concrete placement and removal of excavated material in tunnels and underground, Robot and materials handling technology, Mortar machines, Plastering machines, Screed conveying, Injection and special applications.
Our market fields:

  • Construction
  • Mining and tunnel
  • Power stations
  • Sewage treatment plants
  • Waste incinerators

MODEL OUTPUT UP TO CONCRETE PRESSURE UP TO DRIVE DELIVERY CYLINDER (DIA.) PISTON STROKE
BSA 1005 D 52 m3/ h 70 bar 58 kw 180 mm Ø 1000 mm
BSA 1005 E 49 m3/ h 70 bar 45 kw 180 mm Ø 1000 mm
BSA 1407 D 71 / 47m3/ h 71 / 106 bar 115 kw 200 mm Ø 1400 mm
BSA 1405 E 55 / 37 m3/ h 71 / 106 bar 75 kw 200 mm Ø 1400 mm
BSA 1408 E 79 / 53 m3/ h 71 / 106 bar 110 kw 200 mm Ø 1400 mm
BSA 1409 D 94 / 63 m3/ h 71 / 106 bar 140 kw 200 mm Ø 1400 mm
BSA 2107 HP-E 71 / 47 m3h 150 / 220 bar 200 kw 200 mm Ø 2100 mm
BSA 2110 HP-D 102 /70 m3/ h 150 / 220 bar 330 kw 200 mm Ø 2100 mm
BSA 2109 H-D 95 / 57 m3/ h 91 / 152 bar 200 kw 200 mm Ø 2100 mm
BSA 2109 H-E 85 / 51 m3/ h 91 / 152 bar 160 kw 200 mm Ø 2100 mm
BSA 14000 SHP-D 71 / 36 m3/ h Consult Factory 470 kw 180 mm Ø 2100 mm
BSA 14000 HP-D 102 /70 m3/ h 150 / 220 bar 470 kw 180 mm Ø 2100 mm
BSA 14000 HP-E 95 / 65 m3/ h 150 / 220 bar 2 x 160 kw 200 mm Ø 2100 mm
