IMPROVED POWER DENSITY
FOR STANDBY APPLICATIONS

COOLING SYSTEM

​The new cooling pack has been designed and tested to ensure proper generator set cooling, and includes the radiator, fan, belts, and all guarding installed as standard.

CAT® DIESEL ENGINES

The four-cycle Cat® diesel engine combines consistent performance with excellent fuel economy and transient response that meets or exceeds ISO 8528-5. The engines feature a reliable, rugged, and durable design that has been field proven in thousands of applications worldwide in emergency standby installations.

ENGINE SPECIFICATIONS:

Engine Model: Cat® C18 ACERT In-line 6, 4-cycle diesel

Displacement: 18.1 L (1106.3 in³)

Aspiration: Turbocharged Air-to-Air Aftercooled

Fuel Injection System: Electronic Unit Injection

Governor: Electronic ADEM™ A4

Emission Certifications: EPA TIER II

ALTERNATOR

The new alternator *LC7224 used on Cat packages have been designed and tested to work with the Cat engine. The generators are built with robust Class H insulation and provide industry-leading motor starting capability and altitude capabilities.

ALTERNATOR SPECIFICATIONS:

Alternator Design: Brushless Single Bearing, 4 Pole

Stator: 2/3 Pitch

Available Voltage Options: 600 / 480 / 240 / 220 / 208V

Frequency: 60Hz

Alternator Insulation & IP: Class H; IP23

Available Excitation Options: Self-Excited, AREP

Temperature rise: 125 / 130° C

EMCP 4.2B

Digital control panel with advance protection and remote communications.

Digital Indication: RPM, DC volts, Operation hours, Oil pressure (psi, kPa or bar), Amps (per phase & average), and more…

Warning / shutdown (LED indication) of: Low oil pressure, High coolant temperature, Overspeed, Emergency stop, and more…

Programmable protective relaying functions: Generator phase sequence, Over/Under voltage, Reverse Power and more…

Communications: Customer data link (RS485 Modbus RTu), Serial annunciator module data link for local & remote annunciator, and more…

IVR – Integrated Voltage Regulator (Digital): EM10 Excitation Module

CIRCUIT BREAKER / IVR

FULLY RATED MAINLINE CIRCUIT BREAKER

  • Housed in vibration isolated sheet steel enclosure
  • Oversized electrical stub-up area (can be terminated both vertically and horizontally)
  • Increased rating to *3000A

INTEGRATE VOLTAGE REGULATOR (IVR)

  • Robust, precise closed-loop control of the generator voltage
  • Optimized transient performance
  • Industry leading feature specification
  • Load voltage is kept at +0.5 percent from no load to full load
BASE FUEL TANK

SUB BASE

  • The sub-base fuel tank mounts below the generator set wide base.

INTEGRAL

  • Integral diesel fuel tank is incorporated into the generator set base frame
  • Robust base design includes linear vibration isolators between tank base and engine generator

FEATURES

  • UL listed for United States (UL 142) & Canada (CAN/ULC S601)
  • Facilitates compliance with NFPA 30 code, NFPA 37 & 110 standards & CSA C282 code
  • Compatible with open packages and enclosures
  • Dual wall
  • Lockable fuel fill cap, 4″ (101.6 mm) NPT
