TRUCK MOUNTED CONCRETE PUMPS

BSF 20-4.09H ‒ BSS 70-5.20 H

MODEL SECTIONS REACH HEIGHT REACH DEPTH MAX OUTPUT DELIVERY PRESSURE DELIVERY CYLINDER (DIA.)
BSF 20-4.09 H- 4 19.5 m 11.1m 52 m3/h 78 bar 250 mmÆ
BSF 24-4.09 H 4 23.6 m 14.5m 90 m3/h 78 bar 230 mmÆ
BSF 24-4.11 H 4 23.6 m 14.5m 110 m3/h 78 bar 230 mmÆ
BSF 24-4.11 H LS 4 23.6 m 14.5m 110 m3/h 85 bar 250 mmÆ
BSF 24-4.16 H 4 23.6 m 14.5m 108 m3/h 130 bar 230 mmÆ
BSF 28-4.11 H 4 27.7 m 17.0m 108 m3/h 78 bar 230 mm Æ
BSF 28-4.11 H LS 4 41.6 m 31.0m 160 m3/h 85 bar 230 mm Ø
BSF 28-4.14 H 4 27.7 m 17.0m 110 m3/h 112 bar 250 mm Æ
BSF 28-4.16 H 4 27.7 m 17.0m 140 m3/h 130 bar 230 mmÆ
BSF 31-5.14 H 5 30.5 m 20.4m 80 m3/h 70 bar 125 mmÆ
BSF 31-5.16 H 5 30.5 m 20.4m 140 m3/h 85 bar 230 mmÆ
BSF 31-5.16 H LS 5 30.5 m 20.4m 160 m3/h 85 bar 230 mmÆ
BSF 32-4.14 H 4 31.9 m 20.8m 160 m3/h 70 bar 250 mmÆ
BSF 32-4.16 H 4 30.5 m 20.4m 140 m3/h 85 bar 230 mmÆ
BSF 32-4.16 H LS 4 30.5 m 20.4m 160 m3/h 85 bar 230 mmÆ
BSF 36-4.14 H 4 35.6 m 23.9m 160 m3/h 70 bar 250 mm Ø
BSF 36-4.16 H 4 35.6 m 20.4m 140 m3/h 85 bar 230 mm Ø
BSF 36-4.16 H LS 4 35.6 m 20.4m 160 m3/h 85 bar 230 mm Ø
BSF 38-4.14 H 5 37.1 m 24.4m 160 m3/h 70 bar 250 mm Ø
BSF 38-4.16 H 5 37.1 m 24.4m 140 m3/h 85 bar 230 mm Ø
BSF 38-4.16 HLS 5 37.1 m 24.4m 160 m3/h 85 bar 230 mm Ø
BSF 42-5.14 H 5 41.6 m 31.0m 160 m3/h 70 bar 250 mm Ø
BSF 42-5.16 H 5 41.6 m 31.0m 140 m3/h 85 bar 230 mm Ø
BSF 42-5.16 H LS 5 45.1 m 32.2m 160 m3/h 70 bar 250 mm Ø
BSF 46-5.16 H LS 5 45.1 m 32.2m 140 m3/h 85 bar 230 mm Ø
BSF 47-5.16 H 5 45.1 m 32.2m 160 m3/h 85 bar 230 mm Ø
BSF 47-5.16 H LS 5 46.1 m 32.2m 160 m3/h 70 bar 250 mm Æ
BSF 49-5.16 H 5 46.1 m 32.2m 160 m3/h 85 bar 230 mm Æ
BSF 52-5.16 H 5 46.1 m 33.9m 160 m3/h 85 bar 230 mm Æ
BSF 52-5.16 H LS 5 48.4 m 32.2m 160 m3/h 70 bar 250 mm Ø
BSF 52-5.20 H 5 48.4 m 32.2m 200 m3/h 85 bar 280 mm Æ
BSF 58-5.16 H 5 48.4 m 42.4m 160 m3/h 85 bar 230 mm Ø
BSF 58-5.16 H LS 5 48.4 m 42.4m 160 m3/h 70 bar 250 mm Æ
BSF 58-5.20 H 5 48.4 m 42.4m 200 m3/h 85 bar 280 mm Ø
BSF 62-6.16 HLS 5 61.1 m 44.3 m 160 m3/h 85 bar 230 mm Æ
BSF 62-6.20 H 5 61.1 m 44.3 m 160 m3/h 85 bar 250 mm Ø
BSF 63-5.16 H LS 5 62.1 m 46.3 m 200 m3/h 85 bar 280 mm Ø
BSF 63-5.20 H 5 62.1 m 46.3 m 160 m3/h 85 bar 230 mm Ø
BSS 70-5.16 H 5 69.3 m 51.4m 160 m3/h 85 bar 250 mm Ø
BSS 70-5.16H LS 5 69.3 m 51.4m 160 m3/h 85 bar 280 mm Ø
BSS 70-5.20 H 5 69.3 m 51.4m 200 m3/h 85 bar 280 mm Ø
